3. Features and Specifications:
Main features:
Supports all new AM2/AM3/AM3+/FM1 micro-processors
95x25mm Sleeve bearing fan for silent operation
Extruded heat-sink with massive copper-core for optimal heat conductivity
Specifications:
Heat sink : 81*76.8*38mm
Dimensions
12VDC Fan : 95X95X25 mm
Material AL+CU
Bearing Sleeve Bearing
Cooler 800~2500RPM
Rated speed
Single fan 800~2500RPM
Rated power 2.44 W
Noise level 10.0~26.0dBA
Air flow 48.53 CFM Max.
Current 0.20 A
Life hours Sleeve: 30,000
Connector 4 pin(2510)
Application AMD AM2/AM3 /AM.+/FM1
TDP(Watt) 95W
Thermal
resistance
0.347°C/W
Thermal type Stars-420 grease
weight 403g (Cooler only)
