Spire STARCORE PWM / SP854S3-1-PWM - Manual (Page 10)

Version:A/0 Page 10 of12
Spire Corp.
Http://www.spirecoolers.com & Http://www.spirepower.com
Http://www.spire-corp.com
5. Fan Specification:
FAN MODEL: SF09025SRM3W2-P
1) Rated Voltage : 12VDC
2) Operating Voltage Range : 10.2 ~13.8VDC
3) Rated Speed : 800~2500RPM ±10%
4) Static Pressure : 2.32 mm-H
2
O
5) Air Flow : 48.53
6) Rated Current : 0.20MP
7) Rated Power : 2.4 WATTS
8) Noise Level : 10.0~26.0 dBA
9) Operating Temperature : -10 to 70
0
C
10) Storage Temperature : -40 to 70
0
C
11) Bearing System : Sleeve Bearing
12) Connector : 4pin(2510)
13) Weight : 64.0g
