Parts List
To order parts, contact your Authorized Service Agent. Supply the model designation, serial number, part description, part number,
quantity, and when applicable, voltage and phase.
KEY DESCRIPTION
PART NO.
1
WATER FILL ASSEMBLY
097007
2
SAFETY VALVE
097005
3
CHECK VALVE
004187
4
PRESSURE GAUGE
170003
5
KBS AND TRUNNION, NO TDO 20
KBS AND TRUNNION, NO TDO 40
KBS AND TRUNNION, NO TDO 60
KBS AND TRUNNION, TDO-2 20 KBS
AND TRUNNION, TDO-2 40 KBS AND
TRUNNION, TDO-2 60
153236
153250
153256
153241
153251
153257
6
STAND AND HOUSING ASSEMBLY 20
STAND AND HOUSING ASSEMBLY 40, 60
140842
147855
7
PEDESTAL WELDMENT
138107
8
KNOB THERMOSTAT
170229
9
LIGHT, RED
116383
10
ELECTRICAL MOUNT ASSEMBLY
138123
11
TILT SWITCH
002982
12
CONTACTOR
148102
13
TRANSFORMER, 208/240V/24V 40VA
TRANSFORMER, 480V/24V 40VA
137441
137694
14
GROUND TERMINAL
129714
15
TERMINAL BLOCK
003888
16
FUSE HOLDER
077854
17
FUSE, 3 AMP
077853
18
WATER LEVEL BOARD
122192
19
PRESSURE SWITCH
096963
20
THERMOSTAT
009730
21
WATER LEVEL PROBE
070178
22
ELEMENT, 208V 3.6 KW
ELEMENT, 480V 4 KW
ELEMENT, 208V 9.95 KW
ELEMENT, 240V 8 KW
ELEMENT, 480V 8 KW
011094
011088
005977
005974
005980
23
FOOT, ADJUSTABLE BULLET
FOOT, FLANGED
013275
096569
24
HANDLE, CRANK
013617
KEY DESCRIPTION
PART NO.
25
SHAFT, HANDWHEEL
013624
26
STAND CLADDING 20
STAND CLADDING 40, 60
140424
139056
27
LEG TUBE 20, 40, 60
LEG TUBE 40, 60
001469
147506
28
LEFT FRAME SUPPORT 20
LEFT FRAME SUPPORT 40, 60
137951
146999
29
RIGHT FRAME SUPPORT 20, 40, 60
137953
30
INNER FRAME SUPPORT 20, 40, 60
137954
31
REAR FRAME SUPPORT 20
REAR FRAME SUPPORT 40, 60
140422
146998
32
SHORT FRAME SUPPORT 20, 40, 60
137955
33
PEDESTAL CLADDING ASSEMBLY
138112
34
GEAR BORE
013609
35
WORM GEAR
012026
36
BEARING
009765
37
BEARING HOUSING
009762
38
KEY 3/8”
001474
39
SET SCREW
012060
40
WATER LEVEL ASSEMBLY
065198
41
FITTINGS, SIGHT GLASS ASSEMBLY
002845
42
GUARD, GLASS ROD GAUGE
002981
43
TUBE, WATER LEVEL
008742
44
ELBOW, F 90 DEG 1/2 NPT X 1/2” TUBE
055634
45
BUSHING, REDUCING 1/4” X 1/8” NPT
074872
46
ELECTRODE, WATER LEVEL
002170
x
COVER, BOTTOM 20
003333
x
COVER, BOTTOM 40, 60
003334
x
COVER, SIDE PEDESTAL
001464
x
COVER, TOP PEDESTAL
138114
x
COVER, LOWER TRUNNION SUPPORT
ARM
116308
x
COVER, UPPER TRUNNION SUPPORT
ARM
116305
x
OVERLAY OPERATING INSTRUCTIONS
170011
x
HARNESS, WIRE
148544
x
HARNESS, HIGH VOLTAGE
149942
x
HARNESS, CONTROL
149943
x- Item not depicted/called out in drawing
