20 OM-BLT/BLP-E
To order parts, contact your Authorized Service Agent. Supply the model designation, serial number, part description, part number,
quantity, and when applicable, voltage and phase.
x- Item not depicted/called out in drawing or photograph
Parts List
KEY DESCRIPTION PART NO.
1 STAND ASSEMBLY - 30 144848
1 STAND ASSEMBLY - 40 144332
2 PAN WELDMENT - 30 145654
2 PAN WELDMENT - 40 144789
3 KNOB THERMOSTAT 003908
4 OPERATING THERMOSTAT 002180
5 LIGHT, AMBER 116384
6 TILT SWITCH 143319
7 CONTACTOR 148102
8 GOUND TERMINAL 119829
9 TERMINAL BLOCK 003888
10 FUSE HOLDER 077854
11 FUSE, 3 AMP 077853
12 TRANSFORMER - 208/240V 137441
12 TRANSFORMER - 480V 137694
13 POWER SWITCH 155546
14 HIGH LIMIT THERMOSTAT 142755
15 ELEMENT - 208V 145656
15 ELEMENT - 240V 146185
15 ELEMENT - 480V 149114
16 COVER ELEMENT HOUSING - 30 146186
KEY DESCRIPTION PART NO.
16 COVER ELEMENT HOUSING - 40 144343
17 RIGHT SIDE COVER 145688
18 LEFT TRUNNION COVER ASSEMBLY 144776
19 TILT SWITCH BRACKET ASSEMBLY 145689
20 CONTROL BOX ASSEMBLY 147313
21 ELECTRICAL BOX ASSEMBLY 147315
22 TERMINAL BLOCK BOX 146205
23 TERMINAL BLOCK BOX BOTTOM 146207
x TRANSFORMER, POWER TILT 480V 051469
x OVERLAY, MANUAL TILT 170800
x OVERLAY, POWER TILT 170801
x HARNESS, CONTROL 148538
x HARNESS, POWER 208/240V 148539
x HARNESS, POWER 480V 149291
x HARNESS, ELEMENTS 30 208/240V 148560
x HARNESS, ELEMENTS 30 480V 149293
x HARNESS, ELEMENTS 40 208/240V 148561
x HARNESS, ELEMENTS 40 480V 149292
