Installation, Home/residential dip switch settings, Figure 3-1 home/residential dip switch settings – AT&T Door Phone Controller User Manual
Page 41
LEGEND
1 2 3 4 5 6 7 8
ON
Off On
NOTE: The Forced Disconnect
I
Timeout option does not apply
I— —
when DIP switch position 8 is ON.
ON for
Option Selection
Mode Only
Figure 3-1 Home/Residential DIP Switch Settings
.
Installation
When moving the Door Phone
Connect the Door Phone Controller using the information in
Controller or adding or removing
Section 2. Refer to Figure 3-2.
cables from the back panel,
unplug the transformer from
120V outlet. Also unplug the
terminal strip and modular
phone connectors on the back
panel.
Installation — Home/Residential 3-3
