Mounting at&t door phone controller to wall – AT&T Door Phone Controller User Manual
Page 28
4. When the AT&T Door Phone Controller is securely
mounted to the wall, then all cables and wires can be
connected to the terminal strip and then plugged into
the back panel.
DOOR PHONE
CONTROLLER
BACK PANEL
K E Y H O L E
MOUNTING
S L O T S
5/16'' TYPICAL
8.1''
MOUNTING SCREWS
Figure 2-3. Mounting AT&T Door Phone Controller to
Wall
2-12 Installation Procedures
