Acura 2009 TSX - Manual (Page 438)

Open the hood.
To change the turn signal bulb on
the passenger’s side, remove the
engine coolant reserve tank by
pulling it out of its stay.
Insert the new bulb into the hole,
making sure the tabs are in their
slots.
Push the electrical connector onto
the new bulb. Make sure it is
connected securely.
Pivot the hold-down wire back in
place, and clip the end into the slot.
Reinstall the cover over the back
of the headlight assembly and turn
it clockwise to lock it in place.
Turn on the headlights to test the
new bulb.
Put the inner fender cover in place.
Install the holding clip. Lock it in
place by pushing on the center.
Tighten the screw securely.
Remove the electrical connector
from the bulb by pulling the
connector straight back, then
remove the bulb.
Unclip the end of the hold-down
wire from its slot. Pivot it out of
the way.
1.
8.
7.
9.
10.
11.
12.
5.
6.
Lights
High Beam Headlights
432
STAY
