5
6
7
8
9
10
11
12
13
14
16
17
18
19
VALVE BODY
SHOWN FOR
REFERENCE
15
ITEM DESCRIPTION
ADJUSTMENT STEM LOCK NUT 5
VALVE BONNET 6
BONNET O-RING 7
ADJUSTMENT STEM 8
ADJUSTMENT STEM O-RING 9
SHUTTLE O-RING
10
SHUTTLE
11
ITEM DESCRIPTION
12
THERMOSTATIC MOTOR 13
LOWER SPRING
14
INLET SCREEN (x 2)
15
CHECK VALVE (x 2)
16
CHECK VALVE BONNET O-RING (x 2)
17
CHECK VALVE BONNET (x 2)
18
FUNNEL
UPPER SPRING
19
KIT NUMBER DESCRIPTION
COMPLETE REBUILD KIT 7803-500-001
INTERNAL REPAIR KIT 7803-501-001
BONNET / STEM REPLACEMENT 7803-502-001
CHECK VALVE / STRAINER KIT 7801-503-001
ITEM KIT NUMBER DESCRIPTION ITEM
1
2 3
4
ITEM DESCRIPTION
16
17
18
19
4
5
6
7
8
9
3
4
2
1
NOTE:
Individual parts not available for purchase,
sold in repair kits only. Parts called out for
reference only.
REPAIR PARTS:
Acorn Controls Division of Acorn Engineering Company ® , A member of Morris Group International ™
Manual #7802-115-000 Date: 04/01/14
ST7069 Installation & Operation Manual
O-RINGS SHOULD BE LUBRICATED WITH AN NSF
APPROVED LUBRICANT. CARE SHOULD BE
EXERCISED WHILE INSERTING COMPONENTS
INTO VALVE BODY DURING REASSEMBLY.
!
IMPORTANT
