NOTE;
ALL DIMENSIONS ARE IN INCHES (MM).
ROUGH-IN DIMENSIONS:
Acorn Controls Division of Acorn Engineering Company ® , A member of Morris Group International ™
Manual #7802-115-000 Date: 04/01/14
2
1
2
"
(66)
5
3
4
"
(146)
3
7
8
"
(98)
2"
(51)
1/2" NPT
CONNECTIONS
LOCKNUT
TEMPERATURE
ADJUSTING STEM
INTEGRAL
CARTRIDGE
STYLE
CHECKS
ST7069 Installation & Operation Manual
