Specification – Abocom UBT2K1H User Manual
Page 2
Created on 8/18/2004
Revised on: 4/14/2006
AboCom System, Inc – RD5 division
Product Code: UBT 2K1H
SPECIFICATION
Standard
Bluetooth 1.2
Host Interface
USB1.1
Antenna
Built in the card
LED Indicator
Power LED
Frequency Range
2.4000-2.4835 GHz
Number of Selectable Channels
79 channels
Data rate
Up to 723 Kbps
Typical Range
Devices connect for access and data sharing ranges up to
100 meters
Security
Data encryption up to 128-bits
RF Technology
Frequency hopping spread spectrum(FHSS)
Topology
8 devices
point-to-multipoint
Transmitter Power
Output power meets Class 1
Physical Specifications
Weight: 10 g
Dimension: 69.53 (L) X 26.68 (W) X 9.19 (H) mm
Power Requirement
Normal Operation: 5V DC, 100mA (Max)
Environment Specifications
Operating Temperature: 0~45℃ ambient temperature
Storage Temperature: -20~45℃ ambient temperature
Operating humidity: 90% maximum (non-condensing)
Storage humidity: 90% maximum (non-condensing)
Supported OS
Windows 2000/XP
Sensitivity
-80dBm
Distance
100 M
EMC Certification
FCC CE BQB
