7
Preparing the Disk Drive for Installation
Before installing the disk drive, ensure that it meets the
requirements listed in
Supported Disk Drives on page 5 .
Set the drive jumper to Master or Device 0 mode (or equivalent, as
described on your disk drive), following the instructions on your
disk drive.
Installing a Disk Drive
Note: You need a Phillips screwdriver to complete this task.
To install a disk drive into your USB Enclosure:
1 Use a screwdriver to remove the enclosure cover, as shown
below.
2 Connect the EIDE/IDE connector of your disk drive to the
interface connector inside the enclosure cover.
Interface Connector
Disk Drive Connector
