Appendix A Display Timing Mode and
OSD
A.1 Supported Input Timing Modes
The nineteen kinds of timings below are already programmed in this
module. The input synchronous signals are automatically recognized.
Table A.1: Supported Input Formats
Note 1:
Even if the preset timing is entered, a little adjust-
ment of the functions such as Horizontal period,
CLK-delay and display position, are required. The
adjusted values are memorized in every preset num-
ber.
Note 2:
This module recognizes the synchronous signals
with near preset timing of the frequency of the HS
and Vsync, even in the case that the signals other
than the preset timing that were entered.
Note 3:
Because adjustments may not fit, such as differing
magnifying ratios or, in the case that you use it
except for the display timing that was preset.
56Hz
60Hz
70Hz
72Hz
75Hz
640x480
Yes
Yes
Yes
800x600
Yes
Yes
Yes
Yes
1024x768
Yes
Yes
Yes
Resolution
Vertical Frequencies
