Chapter 2 System Setup
2.5 Attaching cables
Once you have added your cards, drives and other equipment, connect the
display power (see Fig. 2-6, and reattach the cables on the rear panel (see
Fig. 2-7), you should switch on the AWS-8248 and confirm that it works.
Figure 2.6: Connect the display power
Figure 2.7: Cables on the rear panel
