Samsung UE40C8000XW - Manual (Page 9)

9
English
02
Connections
Using a Component (up to 1080p) or Audio/Video (480i only) and Scart Cable
Available devices: VCR, DVD, Blu-ray player, cable box, STB satellite receiver
✎
In Ext.1, Ext.2 mode, DTV Out supports MPEG SD Video and Audio only.
✎
To obtain the best picture quality, the Component connection is recommended over the A/V connection.
P R P B Y
COMPONENT OUT VIDEO OUT AUDIO OUT
R-AUDIO-L
AUDIO OUT
R-AUDIO-L
EXT
G
B
W
R
Y
W
R
Y W R W R R G B
R B G Y W R W R
R
VCR
DVD DVD / Blu-ray
player
Red Red White White Yellow Red Blue Green
