10
ITEM PART NUMBER DESCRIPTION QUANTITY
10. PARTS LIST & EXPLODED VIEW
PARTS LIST
ELEMENT, CERAMIC, 208V 1 94000028 AS R'QD
94300001 ELEMENT, CERAMIC, 240V AS R'QD
FIREBAR ELEMENT, XWAV1417, 208V 2 94100016 1
94400001 FIREBAR ELEMENT, XWAV1417, 240V 1
3 96100001 ESCUTCHEON, XWAV 1417A 1
4 96100002 WELD ASSY, CONVEYOR, XWAV 1417A 1
END, CAP, F/L & B/R 5 93000067 4
END CAP, B/L & F/R 6 93000070 4
7 82914 CHAIN, CONVEYOR DRIVE, XWAV1417, 1422, 1829 1
WIRE BELT, XWAV1417 & 1422 8 94100043 1
9 94200097 ASSY, MERKLE-KORFF GEAR MOTOR 1
10 94200095 KIT, POWER SUPPLY, 5V/24V OUTPUT 1
11 95000033 TERMINAL BLOCK, CERAMIC AS R'QD
12 85283 FAN CORD 2
13 85287 FAN GUARD 2
14 85284 FAN,COOLING 2
15 30203 TERMINAL BLOCK, 2 POLE 1
16 86295 LEG, BLACK 4
17 94000105 THERMOSTAT 2
18 94100048 POWER CORD, 12/3, 6-30P 1
19 96100010 INSTALLATION/OPERATION MANUAL, XWAV 1417A 1
20 67002 SWITCH, ON-OFF, 30 AMP, DPST 1
21 88705 KNOB, BLACK 3
22 94100029 TRAY, CONVEYOR, XWAV 1417 2
23 94100045 CONVEYOR, EXTENSION, XWAV 1417, XWAV 1422 AS R'QD
24 69104-EGO 208V INFINITE CONTROL-EGO 1
26 94000189 STACKING BRACKET KIT (OPTIONAL) 1
27 94000172 ASSY, POTENTIOMETER 1
28 96100007 PROTECTOR, EGO SWITCH 1
25 89408 SWITCH, LIGHTED ROCKER 1
69103-EGO 240V INFINITE CONTROL-EGO 1
