16
English
Menu Item initial Value Description
REACH
Solution
REACH Update Time …
Lets you set when data such as updated SW, cloning files, and S-LYNC REACH
contents is downloaded from the REACH server to the TV :
y 1hour : Every hour
y 2hour : Every 2 hours
y 12:00 am : every 12:00 a.m.
y 12:00 pm : every 12:00 p.m.
y 2:00 pm : every 2:00 p.m.
REACH Update
Immediate
…
y On : Whenever the TV enters standby mode (the power cord is plugged in and the
power is off), the REACH data is updated on the TV.
y Off : The REACH data is only updated on the TV at the REACH server update
time.
Room Number … Setting Room Number.
REACH 2.0 TV Sound …
y OFF:Close REACH 2.0 TV Sound
y ON:Open REACH 2.0 TV Sound
REACH 2.0 Server
Version
… 0000:Displays the current REACH data version.
DRM
DRM Mode Pri:idiom
Configures CAS support. Applies to only the NB673, NB677, and NB678 models.
OFF : Turns off CAS support.
LYNK DRM : Select to turn on S-LYNK DRM CAS support only.
Pro:idiom : Select to turn on Pro:Idim CAS support only.
LYNK DRM,PI : Select to have the TV support S-LYNK DRM CAS and Pro:Idiom CAS.
PI AES Data 0xD279 Displays the current state of Pro:Idion AES
PI AES Log OFF
PI AES Log consists of Pro:Idiom AES diagnostic register, here after referred as AESD,
values. These register log will help us diagnose PI key loss issue in the field and provide
solution for it.
View PI AES Log … Displays Pro:Idion AES Log OSD
System
Self Diagnosis for TV
Lets you check the state of the TV picture and sound.
y Picture Test : Use to check for picture problems. If the problem appears in the test
picture, select YES, and then follow the directions on the screen.
y Sound Test : Use to check for sound problems. If the problem occurs during the
test, select YES, and then follow the directions on the screen.
Self Diagnosis for HTV
Lets you check the state of Pro:Idiom and its communication with the SI STB or SBB.
If you have any problems with the Pro:idiom encryption channel or the communications
with the SI STB or SBB, use this diagnosis function.
If Pro:Idiom DTV Channel Key Loss appears to have failed and the Pro:Idim encryption
channel has failed to play content, first check the broadcasting systems related to
Pro:Idiom encryption. If your broadcasting system does not have a problem, contact
Samsung Service.
If STB SI Vendor Setting appears to have failed and communication with the SI STB or
SBB has failed, first check your SI STB or SBB. If your SI STB or SBB does not have a
problem, contact to Samsung Service
SW Update Lets you upgrade the TV SW with a USB memory stick. See Page 31.
Service Pattern OFF
Lets you check the state of the TV picture by displaying picture test patterns. Press the
Menu button to turn off the test patterns and exit.
ATV Cable AGC Gain
Lets you control the AGC gain of the analog cable channels. Don't change the default
value unless problems occur.
DTV OpenCable AGC
Gain
Lets you control the AGC gain of the digital cable channels. Don't change the default
value unless problems occur.
Contact Samsung Samsung Contac information
TV Reset Returns all settings on the TV to their factory defaults.
✎
REACH (Remote Enhanced Active Control for Hospitality) is a professional, interactive remote controller that lets you
deliver TV firmware updates, cloning data, channel maping changes, S-LYNK REACH contents, and TICKER contents
through RF DTV to several hundred hospitality TVs simultaneously. The REACH functions are avalible only in standalone
mode. The REACH Server is sold separately. Refer to the REACH server manual enclosed with the REACH server
product for more operating information.
