Appendices 79
Reversing Adaptors and Cables
Table B.3 lists the reversing adaptors and reversing cables available from Avocent.
Figure B.2 shows the pin assignments for the adaptors listed in Table B.3.
Table B.3: Reversing Adaptors and Cables
Part Number Description
210094 RJ-45 to DB-9M (DTE) Adaptor
210095 RJ-45 to DB-9F (DCE) Adaptor
210090 RJ-45 to DB-25M (DTE) Adaptor
210092 RJ-45 to DB-25M (DCE) Adaptor
210091 RJ-45 to DB-25F (DTE) Adaptor
210093 RJ-45 to DB-25F (DCE) Adaptor
210105 RJ-45 to RJ-45 Male Adaptor for Cisco and Sun Netra console port
690226 10 foot 8-wire Reversing Modular Cable
690227 25 foot 8-wire Reversing Modular Cable
690228 75 foot 8-wire Reversing Modular Cable
750122 Wiring Starter Kit (8-wire) - includes all the above adaptors and one 690226 cable
