AUDIO IN
Connect the audio cable for your product to
the audio port on the back of your computer.
AUDIO OUT
Headphone output terminal
USB connection ter-
minal (Option)
UP (USB upstream port)
Connect the UP port of the product and
the USB port of the computer with the USB
cable.
DOWN (USB downstream port)
Connect the DOWN port of the USB
product and a USB device with the USB ca-
ble.
Note
To use DOWN (Downstream Port), you
have to connect the UP (Upstream Ca-
ble ) to the PC.
Make sure to use the USB cable supplied
with this product to connect the product's
UP port and your computer's USB port.
Kensington Lock
The Kensington lock is a device used to
physically fix the system when using it in a
public place.
(The locking device has to be purchased
separately.)
Note
For using a locking device, contact where
you purchase it.
Stand Stopper (Only ap-
plied to HAS or HAS-USB
type stand.)
Introduction
