Samsung LS22CRNSF-XAA - Manual (Page 51)

Model
General
General
Model Name SyncMaster 2280HD
LCD Panel
Size 22" Wide diagonal (55 cm)
Display area 473.76 mm(H) x 296.1 mm(V)
Pixel Pitch 0.282 mm(H) x 0.282 mm(V)
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 56 ~ 75 Hz
Display Color
16.7 M Colors
Resolution
Optimum resolution 1680 x 1050 @ 60 Hz < Analog/Digital >
Maximum resolution 1680 x 1050 @ 60 Hz < Analog/Digital >
Input Signal, Terminated
RGB Analog
TTL level (V high ≥ 2.0V, V low ≤ 0.8V)
0.7 Vp-p 5%
Maximum Pixel Clock
135MHz
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Signal Cable
15pin to 15pin D-sub cable, Detachable
DVI-D to DVI-D connector, Detachable(Sold separately)
Signal connectors
15pin 3-row D-sub connector, 24pin 3-row DVI-D connector
19pin Type A HDMI Conntector, Composite, S-Video, Component, RF
Dimensions (WxHxD)/ Weight
SyncMaster 2280HD
