Wall Installation Instructions
1
Do not install the PDP in any location other than a vertical wall.
2
To protect the performance of the PDP and prevent problems, avoid the following
locations :
• Next to smoke and fire detectors.
• Areas subject to vibration.
• Areas subject to high voltage.
• Near or around any heating apparatus.
3
Use only recommended parts and components.
Installation Notes
Parts
(Wall attachment panel is sold separately. Check with your dealer.)
➤
➤
This wall mount bracket installation guide is for the following model : HP-P5091
Insulation Holder :
4 EA
SCREW! : 4 EA SCREW@ : 12 EA
1EA
2EA
LEFT :1EA
RIGHT :1EA
Wall Mount Bracket
ASSY-HINGE
Support Bars
Screws
