Page 2

10. Using the TV's Controller (Panel Key)

The TV's Controller, a small joy stick like button on the rear right side of the TV, lets you control the TV without the remote

control. To use the controller, push it forwards, backwards, left, or right. To make a selection, press up.

Function menu

Remote control sensor

TV Controller

The image is drawn as if you are

facing the front of the TV.

MEDIA.P

m R s

Return

Select Media Play

Select a Source
Power Off

Select the Menu

✎

To close the Menu, Media Play List, or Source List, press the Controller for more than 1 second.

✎

When selecting a function by pushing the controller forwards, backwards, left, right, be sure not to press up on the

controller before you reach your selection. If you press up on the controller, it will stop operating in the forwards,

backwards, left, and right directions.

11. Warranty Information

SAMSUNG BRAND PRODUCTS

LIMITED WARRANTY TO ORIGINAL

PURCHASER

This SAMSUNG brand product, as supplied and distributed by SAMSUNG

and delivered new, in the original carton to the original consumer purchaser,

is warranted by SAMSUNG against manufacturing defects in materials and

workmanship for period of: (90 Days Parts and Labor for Commercial Use)

Categories

Parts Labor

Size

Service

LCD/LED TV

1 Year 1 Year

39”

and Larger

Carry-In or In

Home

37”

and Smaller

Carry-In

Plasma Display

1 Year 1 Year

All

Carry-In or In

Home

Projector

(Excluding Lamp **) 2 Year 2 Year

All

Carry-In or

Pick up

PICO & LED

Pocket Projector

1 Year 1 Year

All

Carry-In or

Pick up

3D Glasses

1 Year 1 Year

Carry-In or

Pick up

** 180 Days after Purchasing and 600 Hours of Use Lamp on Projector
This limited warranty begins on the original date of purchase, and is valid

only on products purchased and used in the United States. To receive

warranty service, the purchaser must contact SAMSUNG for problem

determination and service procedures. Warranty service can only be

performed by a SAMSUNG authorized service center. The original dated

bill of sale must be presented upon request as proof of purchase to

SAMSUNG or SAMSUNG's authorized service center.
SAMSUNG will repair or replace this product, at our option and at no

charge as stipulated herein, with new or reconditioned parts or products if

found to be defective during the limited warranty period specified above. All

replaced parts and products become the property of SAMSUNG and must

be returned to SAMSUNG. Replacement parts and products assume the

remaining original warranty, or ninety (90) days, whichever is longer.
Certain products are eligible for In-home service at Samsung’s discretion.

To receive in-home service, the product must be unobstructed and

accessible to service personnel. If during in-home service, repair cannot

not be completed, it may be necessary to remove, repair and return the

product. If in-home service is unavailable, SAMSUNG may elect, at our

option, to provide for transportation of our choice to and from a SAMSUNG

authorized service center. Otherwise, and for 37" and smaller LCD/LED TV,

transportation to and from the SAMSUNG authorized service center is the

responsibility of the purchaser.
This limited warranty covers manufacturing defects in materials and

workmanship encountered in normal, and except to the extent otherwise

expressly provided for in this statement, noncommercial use of this

product, and shall not apply to the following, including, but not limited to:

damage which occurs in shipment; delivery and installation; applications

and uses for which this product was not intended; altered product or

serial numbers; cosmetic damage or exterior finishes; accidents, abuse,

neglect, fire, water, lightning or other acts of nature; use of products,

equipment, systems, utilities, services, parts, supplies, accessories,

applications, installations, repairs, external wiring or connectors not

supplied or authorized by SAMSUNG which damage this product or

result in service problems; incorrect electrical line voltage, fluctuations and

surges; customer adjustments and failure to follow operating instructions,

cleaning, maintenance and environmental instructions that are covered

and prescribed in the instruction book; reception problems and distortion

related to noise, echo, interference or other signal transmission and

delivery problems; brightness related to normal aging, or burned-in images.

SAMSUNG does not warrant uninterrupted or error-free operation of the

product.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE
LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES WHETHER

EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY

IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR

A PARTICULAR PURPOSE, SHALL APPLY AFTER THE EXPRESS

WARRANTY PERIODS STATED ABOVE, AND NO OTHER EXPRESS

WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR

CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE

BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR

LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS

OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR

CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR

INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL

THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG

HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR

SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN

AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY

SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING

THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY

FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER’S

PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING

OUT OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT

SOLD BY SAMSUNG NOT CAUSED DIRECTLY BY THE NEGLIGENCE

OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND

TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS

PRODUCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE

REMEDY.
Some states do not allow limitations on how long an implied warranty lasts,

or the exclusion or limitation of incidental or consequential damages, so the

above limitations or exclusions may not apply to you. This warranty gives

you specific legal rights, and you may also have other rights which vary

from state to state. To obtain warranty service, please contact SAMSUNG

at:

Samsung Electronics America, Inc.

85 Challenger Road

Ridgefield Park, NJ 07660-2112

1-800-SAMSUNG (726 -7864) – www.samsung.com

1-800-749-0260: Projectors only

Important Warranty Information Regarding

IMPORTANT WARRANTY INFORMATION REGARDING

TELEVISION FORMAT VIEWING

Standard screen format televisions with aspect ratios of 4:3 (the

ratio of the screen width to screen height) are primarily designed

to display standard format full-motion video.
The images displayed on them should primarily be in the standard 4:3

ratio format and be constantly moving. Displaying stationary graphics

and images on-screen, such as the dark top and bottom letterbox

bars (wide screen pictures), should be limited to no more than 15% of

the total television viewing per week.
Wide screen format televisions with aspect ratios of 16:9 (the

ratio of the screen width to screen height) are primarily designed

to display wide screen format full-motion video.
The images displayed on them should primarily be in the wide screen

16:9 ratio format, or expanded to fill the screen if your model offers

this feature, and constantly moving. Displaying stationary graphics

and images on screen, such as the dark side-bars on non-expanded

standard format television video and programming, should be limited

to no more than 15% of the total television viewing per week.
Additionally, viewing other stationary images and text such as stock

market crawls, video game displays, station logos, web sites or

computer graphics and patterns, should be limited as described

above for all televisions. Displaying any stationary images that exceed

the above guidelines can cause uneven aging of LED Display Panels

that leave subtle, but permanent burned-in ghost images in the

television picture. To avoid this, vary the programming and images,

and primarily display full screen moving images, not stationary

patterns or dark bars. On television models that offer picture sizing

features, use these controls to view the different formats as a full

screen picture.
Be careful in the selection and duration of television formats

used for viewing. Uneven aging as a result of format selection

and use, as well as other burned-in images, is not covered by

your Samsung limited warranty.

7. Initial Setup

When you turn the TV on for the first time, a sequence of screens and on-screen prompts will assist you in configuring the

TV's basic settings. After you plug the power cord into a wall outlet, press the

POWER

button to turn on the TV. Then,

follow the instructions on the TV screen to configure the TV's basic settings.

✎

If you are not using a cable box or satellite box, make sure you have connected the TV to an antenna or cable

connection before you turn on the TV.

✎

To connect the power cord and antenna, refer to `6. Making Connections'.

8. Changing the Input Source

Source List

When you are watching TV and you want to watch a movie on your DVD player or Blu-ray player or switch to your cable

box or STB satellite receiver, you need to change the Source.
1. Press the

SOURCE

button on your remote.

2. Use the

▲/▼ buttons to select an external input source.

■

TV / AV / Component / HDMI1 / HDMI2/DVI

✎

You can only choose external devices that are connected to the TV. In the Source List, connected inputs are

highlighted.

How to Use Edit Name

Edit Name lets you associate a device name to an input source. To access Edit Name, press the

TOOLS

button when

the Source List is displayed. Select the name of the device connected to specific input jacks to make your input source

selection easier.

✎

If you connect a PC to the

HDMI IN 2 (DVI)

port with an HDMI cable, assign PC to HDMI 2 in Edit Name.

✎

If you connect a PC to the

HDMI IN 2 (DVI)

port with an HDMI to DVI cable, assign DVI PC to HDMI 2 in Edit Name.

✎

If you connect an AV device to the

HDMI IN 2 (DVI)

port with an HDMI to DVI cable, assign DVI to HDMI 2 in Edit

Name.

9. Accessing and Using the Main Menu

Your TV's Main menu contains functions that let you control many of the TV's features. For example, in the Main menu

you can change the size and configuration of the picture, its brightness, its contrast and so on. There are also functions

that let you control the TV's sound, channel configuration, energy use, and a host of other features. To access the main,

on-screen menu, press the

(m) button on your remote.

To use the Main menu, press the

▲/▼ buttons to move between the main option categories: Picture, Sound, Channel,

etc. Each time you press a

▲/▼ buttons, the main category name on the left side of the menu changes.

To select a menu option in one of the categories, press the

► button or the

ENTER

E button. Press it again or press

ENTER

E to see the values or choices associated with that option. Usually, you would then press

ENTER

E to select a

value or choice. Press the

RETURN

button or the

◄ button to return to a previous screen or selection.

6. Making Connections

Connect your TV to an antenna or cable connection, and then connect your peripherals. When done, connect the power

cord to the TV, and then connect the power cord to an AC wall outlet. If you are connecting your TV to a cable or satellite

box using HDMI, Component, or Composite connections, you do not need to connect the ANT IN jack to an antenna or a

cable connection.

�

For the best picture and audio quality, connect digital

devices using an HDMI cable.

�

If you connect an external device to the TV that uses

an older version of HDMI, the video and audio may not

work. If this occurs, ask the manufacturer of the device

about the HDMI version and, if it is out of date, request

an upgrade.

�

Be sure to purchase a certified HDMI cable. Otherwise,

the picture may not display or a connection error may

occur.

�

PC/DVI AUDIO IN input is not supported.

�

To connect an HDMI to DVI cable to the TV, you must

use the

HDMI IN 2 (DVI)

jack.

�

For PCs with DVI video out jacks, use an HDMI to DVI

cable to connect the DVI out on the PC to the

HDMI IN

2 (DVI)

jack on the TV. Use the PC's speakers for audio.

�

For a Set-top box connection using an HDMI cable, we

highly recommend you connect the cable to the

HDMI

IN 1 (STB)

jack.

- 6 -

- 5 -

- 7 -

- 8 -

Audio connection (Digital)

Digital Audio System

Audio connection (Analog)

DVD / Home Theater

AUDIO IN

L-AUDIO-R

HDMI OUT

AUDIO OUT

L-AUDIO-R

AUDIO OUT

L-AUDIO-R

COMPONENT OUT

DVI OUT

ANT OUT

VIDEO OUT

OPTICAL

TV Rear Panel

VHF/UHF Antenna

Cable

USB

PC connection

(Using an HDMI (to DVI) Cable)

HDMI connection

Set-top box / Blu-ray

player / DVD

Component connection

Blu-ray player / DVD

AV connection

VCR / Blu-ray player

Power Input

[UF5000_39_ZA-QSG]BN68-04465C-03Eng-1017.indd 2

2013-10-25 오전 8:56:21
