Section 2: Understanding Your Phone 27
Battery
Section 2
Important: Using a non-supported battery may cause damage to your
phone. Use a Samsung supported battery only.
Install the Battery
1. Slide the battery cover down and lift up to remove it.
2. Insert the top end of the
battery in the direction of the
arrow printed on the battery
into the phone housing. The
gold contacts on the top of
the battery should match up
with those on the phone.
3. Push the bottom end of the
battery down until it snaps
into place.
4. Slide the battery cover up
until it snaps into place.
Remove the Battery
1. Slide the battery cover down
and lift up to remove it.
2. Use your finger to lift the
battery (bottom end first) up
and away from the phone.
