Samsung LS19B220NW-ZA - Manual (Page 75)

75
10 Specifications
10
Specifications
10.1 General
Model Name S19B220B S19B220NW S22B220BW
Panel Size 18.5 Inches (47 cm) 19.0 Inches (48 cm) 22.0 Inches (55 cm)
Display area 409.8 mm (H) x
230.4 mm (V)
408.24 mm (H) x
255.15 mm (V)
473.76 mm (H) x
296.1 mm (V)
Pixel pitch 0.300 mm (H) x
0.300 mm (V)
0.2835 mm (H) x
0.2835 mm (V)
0.282 mm (H) x
0.282 mm (V)
Synchronization Horizontal
Frequency
30 ~ 81 kHz
Vertical
Frequency
56 ~ 75 Hz
Display Color 16.7 M
Resolution Optimum
Resolution
1366 x 768 @ 60 Hz 1440 x 900 @ 60 Hz 1680 x 1050 @ 60 Hz
Maximum
Resolution
1366 x 768 @ 60 Hz 1440 x 900 @ 75 Hz 1680 x 1050 @ 60 Hz
Maximum Pixel Clock 89 MHz
(Analog, Digital)
137 MHz
(Analog)
146 MHz
(Analog, Digital)
Power Supply This product uses 100 to 240V.
Refer to the label at the back of the product as the standard voltage can
vary in different countries.
Signal connectors 15pin-to-15pin
D-sub cable,
Detachable
DVI-D to DVI-D
connector,
Detachable
15pin-to-15pin
D-sub cable,
Detachable
15pin-to-15pin
D-sub cable,
Detachable
DVI-D to DVI-D
connector,
Detachable
Dimensions
(W x H x D) /
Weight
Without
Stand
443.3 x 266.4 x
60.8 mm
17.5 x 10.5 x
2.4 Inches
439 x 290 x
60.25 mm
17.3 x 11.4 x
2.4 Inches
505.5 x 331.5 x
60.25 mm
19.9 x 13.1 x
2.4 Inches
With
Stand
443.3 x 342.6 x
200 mm / 3.05 kg
17.5 x 13.5 x
7.9 Inches / 6.7 lbs
439 x 367 x
200 mm / 3.15 kg
17.3 x 14.4 x
7.9 Inches / 6.9 lbs
505.5 x 408.8 x
200.0 mm / 3.25 kg
19.9 x 16.1 x
7.9 Inches / 7.2 lbs
VESA Mounting Interface 100 mm x 100 mm
3.9 Inches x 3.9 Inches
