English - 2

Selecting a Source

To watch a movie on your Blu-ray player or watch your favorite TV show, you must

select the correct source. A source is a device, such as a Blu-ray/DVD player, a

cable/satellite box, antenna or a cable TV input. Sources can be connected to

your TV through the HDMI, DVI, Component, Composite, or D-sub connections, or

through the Antenna or Cable In connections.
To view the signal from a source connected to the

HDMI, DVI, Component, Composite, or D-sub

jack, press the

SOUrCE

button on your remote.

Each time you press the

SOUrCE

button, you

change to a different source.

Viewing the On Screen Menus

To view the On Screen Menus, follow these steps:

1. With the power on, press the

button

on your remote. The main menu appears.

The menu’s left side has the following menu

options: Picture, Sound, Channel,

Setup, Input, Application, and Support.

2. Press the

▲ or ▼ button on your remote to

select a menu option, and then press the

EnTErE

button.

3. When done using the menu, press the

ExIT

button on your remote to exit.

BN68-03204A-00

Setting the Clock

Before you can use your TV’s On/Off Timer, you must set the clock. To set the

clock, follow these steps:

1. Turn on your TV.
2. Using your remote, press the

button on your remote.

Then, select Setup

→ Time.

3. Select Clock Mode, and then

press the

EnTErE

button.

Set Clock Mode to Manual.

Select Auto if you have a digital

✎

channel in your area and are not

using a cable/sat box.

4. Select Clock Set, and then press

the

EnTErE

button.

The Clock Set screen appears.

5. Using the number buttons on your remote, enter the Month, Day, year, Hour,

and Minute. Use the

◄ or ► button to move between entry fields.

6. Press the

rETUrn

button on your remote when done.

Connecting a USB Device for Media Play

you can enjoy photo, music, and movie files stored on

a USB device by connecting it to the TV and using the

Media Play feature. To connect a USB device for Media

Play, follow these steps:

1. Turn on your TV.
2. Connect a USB device

containing photo, music and/or

movie files to the

USB

jack on

the rear of the TV.

3. When the Application selection

screen appears, press the

EnTErE

button on your

remote to select Media Play

(USB).

Remote Control Buttons and Functions:

Changing the Picture Mode

Your TV has three preset Picture Modes with factory adjusted settings, each

designed to give you an excellent picture under specific conditions.
The Picture Modes are listed and described in the table below:

Mode

Description

Dynamic

Brightens picture. For a vibrant, enhanced image in brightly lit or

sunny room.

Standard

For a bright, detailed picture in a normally lit room.

Movie

For a studio quality cinema picture in a dimly lit or dark room.

To change the Picture Mode, follow these steps:

1. Turn on your TV.
2. Using your remote, press the

button on your remote.

Then, select Picture

→ Mode.

3. On the Picture Mode menu, use the

◄ or ► on your remote to select

the Picture Mode you want.

4. Press the

ExIT

button to exit the menu.

Changing Channels and Adjusting the Volume

Change the channels by pressing
the

button on the remote.

If your TV is attached to a cable

✎

or satellite box, you change the

channel using the box’s remote.

Adjust the volume by pressing the

button on the remote.

You can also change the channels by pressing the

buttons on the front

panel of your TV and adjust the volume by pressing the

buttons.

Move

Adjust

Enter

return

Clock Set

Month

Day

year

Hour

Minute

am/pm

----

TV Rear Panel

USB Drive

Media

Play

Videos

SUM

Change Device

View Devices E Enter R return

MEDIA.P

Return to the previous channel.

Press to switch between the sources (Blu-ray player,

cable box, DVD player, etc.) connected to your TV.

MTS

: Press to choose stereo, mono or Separate

Audio Program (SAP broadcast).

P.SIZE

: Picture size selection.

: Controls the caption decoder.

Cut off the sound temporarily.

Display Favorite Channel Lists on the screen.

Press to display information on the TV screen.

Exit the menu.

Change channels.

Display the main on-screen menu.

Press to select additional digital channels broadcast by

the same station. For example, to select channel 54-3,

press 54, press -, and then press 3.

Press number buttons for direct access to channels.

Turns the TV on and off.

Displays the channel list on the screen.

Quickly selects frequently used functions.

Use these buttons to select On Screen Menu items and

change menu settings.

Return to the previous menu.

View the

Media Play

Colored buttons for use in the

Channel List, Media Play

menu, etc.

Adjust the volume.

MEDIA.P

Channel

Volume

MEDIA.P

Power Indicator

Remote control sensor
