CONTROLLERS
3
ABOUT CP7317RS - RS-232 CONTROLLER
2
The CP7317RS RS-232 Controller is designed to
provide expanded capabilities to any control
system. The CP7317RS is designed to accept RS-
232 commands from a control device and output
those commands as relay contacts or digital high or
low. The CP7317RS also is able to convert digital
inputs through I/O ports to the preprogrammed RS -
232 command. There are a variety of applications
that are available with this versatile and very
flexible controller. The CP7317RS has one RS-232
port, 16 relay contacts, and 32 digital I/O pins. The
unit can be easily set-up and controlled using
Windows software.
TECHNICAL SPECIFICATIONS
3
FEATURES/DESCRIPTION
CP7317RS
GENERAL
RS-232
9-pin D Female
Digital I/O Ports
(4) 9-pin D Female
Relays
(5) 5-pin terminal block
connectors
Table 1. CP7317RS General
MECHANICAL
CP7317RS
Width (inches)
8.50in (216mm)
Height (inches)
1.75in (44mm)
Depth (inches)
4.93in (125mm)
Weight (pounds)
2.0lbs (0.91kg)
Ship Weight (pounds)
4.0lbs (1.82kg)
Material
0.1” Al
Finish
Gray
Front/Back Panels
Lexan
T° Operating
10°C-35°C
T° Maximum
50°C
Humidity
90% non-condensing
MTBF (calculations)
40,000hrs.
Table 2. CP7317RS Mechanical
ELECTRICAL
CP7317RS
Baud Rate
Default
2400
Max
19,200
Handshake
Default
8 bit, No parity, & 1
stop bit
Relay Max Voltage
non-inductive
I/O Max voltage
25ma sink@12v
0.1ma source
Power
Internal Power Supply
90-140/200-240 V AC
Power Consumption
10 watts max.
Table 3. CP7317RS Electrical
