CONTROLLERS
13
33
Power up status of relays on port
2,3,4. If bit is set to 0 then relay will
be closed on power up. If bit is set to
1 then relay will be open on power
up.
34
Left bracket for beginning command
code. Factory set to “[“.
35
Right bracket for ending command
code. Factory set to “]“.
36
Power on default status of digital
port 1
37
Power on default status of digital
port 2
38
Power on default status of digital
port 3
39
Power on default status of digital
port 4
40
Not available / Do not read or write
into this location.
.
.
.
.
127
Not available / Do not read or write
into this location.
128
User programmable
.
.
.
.
255
User programmable
4.10.2. MEMORY 2
I/O port / memory is B
Sub-Register address is from 00 to 255
Sub-Register definitions
00
User Programmable
.
.
.
.
.
.
255
User programmable
4.10.3. MEMORY 3
I/O port /memory is C
Sub-Register address is from 00 to 255
These registers are used to feed back code for
transition of input I/O pins from 1 to 0. If any of
the I/O pins are designated as inputs then these
pins will produce RS-232 code when shorted to
ground and another code when they transition
from 0 to 5 volts. The maximum feedback code
length is 8 bytes. Each pin is assigned to a
location of the memory.
Sub-Register definitions
00
00-7 locations for return code for
port 1 pin 1 for transition from 0 to 1.
This return code should include any
necessary brackets.
.
.
.
.
.
.
07
end of return code
08
00-07 locations for return code for
port 1 pin 2 for transition from 1 to 0.
This return code should include any
necessary brackets.
.
.
.
.
.
.
15
end of return code
Default return code is in the following format
[Px.yd]
x
port number 1, 2, 3, 4
y
pin number 1, 2, 3, 4, 5, 6,
7, 8
d
direction U for 0->1 or D for
1->0 transition
4.10. 4. MEMORY 4
I/O port / memory is D
Sub-Register address is from 00 to 255
These registers are used to feed back code for
transition of input I/O pins from 0 to 1. If any of
the I/O pins are designated as inputs then these
pins will produce RS-232 code when shorted to
ground and another code when they transition
from 0 to 5 volts. The maximum feedback code
length is 8 bytes. Each pin is assigned to a
location of the memory.
Sub-Register definitions
00
00-07 locations for return code for
port 1 pin 1 for transition from 1 to 0.
This return code should include any
necessary brackets.
.
.
07
end of return code
