English - 12
✎ For the best cable connection to this product, use cables no thicker than the cable illustrated below:
• Maximum thickness - 0.55 inches (14mm)
Using a Component Cable (up to 1080p HD signals) or an Audio/Video Cable (480i analog signals
only)
Use with DVD players, Blu-ray players, cable boxes, STB satellite receivers, VCRs.
Red White
Red
Red
Blue
White
Green
Yellow
Component Cable
(Not Supplied) Video Cable
(Not Supplied) Audio Cable (Not Supplied) Audio Cable (Not Supplied)
Device Device
✎ For better picture quality, we recommend the Component connection over the A/V connection.
✎ When you connect a Video cable to AV IN , the color of the AV IN [VIDEO] jack (green) will not match
the video cable (yellow).
