< For 28inch model >

Fit the Base and Stand Mount
together, making sure the notch
on the Stand Mount aligns with the
Base.

Insert 4 screws and secure the Base
to the Stand Mount.

x4 (M4 X L12)

Holding the stand parallel to the
screen, slide the Stand Mount into
the notches on the back of the TV.

Insert 3 screws, and then use a
screwdriver to secure the stand to
the TV.

x3 (M4 X L12)
