Technical Specifications Check the CD-R/RW Drive
(Windows 95/NT 4.0)
8 9
SAMSUNG continually strives to improve its products. Both the design specifications
and these user instructions are thus subject to change without notice.
CD-RW
12 cm or 8 cm
900kb/s (MAX)
PIO Mode 3, DMA Mode 1
DISC
WRITING METHOD
ERROR RATE
REAR PANEL
FRONT PANEL
OPERATING
ENVIRONMENT
GENERAL
DRIVE PERFOR-
MANCE
Writing Disc kinds
Reading Disc Types
Erasing Disc Kind
Disc Diameter
Data Transfer Rate
Access Time (1/3 stroke)
Data Buffer Capacity
Laser
Side Motor
SpindlelMotor
Loading Mechanism
Eject Button
Green Indicator(LED)
Red Indicator(LED)
Headphone Output
Volume Control
Required Power
Interface Connector
Audio Output
Jumper Block
Work Area
Storage Area
Dimensions
Weight
RELIABILITY
MTBF
Disc Compartment Loading
CD-DA, CD-ROM Mode-1, CD-ROM XA Mode-2 Form-1,
Form-2, Photo-CD (Single, MultiSession), Video CD ready,
CD-Plus, CD-Extra, Enhanced CD, CD-I/FMV
CD-R, CD-RW
350ms (Typical)
1MB
Semiconductor Laser
Gear Motor
Brushless Motor
Tray, DC motor(Soft Eject)
Disc At Once, Session At Once, Track At Once,
Variable Packet Writing, Fixed Packet Writing
Mode 1: 1 block/10 12 , Mode 2: 1 block/10 9
Writing a Disc (CD-R or CD-RW Disc)
Auto Eject or Auto Inject
Busy or Place a Disc in the tray
Stereo Mini-jack(Ø3.6mm)0.60±20%(Vrms)33 Ω
Wheel Type
+5VDC 1.6A, +12VDC 0.4A (MAX)
ATAPI (EIDE)
Line out 0.70 ±20% (Vrms), 47k Ω
Device Configuration Jumper(MOLEX 70203)
Temperature : -40~60°C, Humidity : 5~90%
Temperature : 5~45°C, Humidity : 8~80%
146(W) x 41.5 (H) x 206(D)mm (Including Bezel)
1000 g
100,000 POH (Duty 25%)
30,000 times
SECTIONS SCW-230 Check the CD-R/RW Drive
You must check the CD-R/RW drive to operate rightly in the Windows 95/NT 4.0
My Computer
Control
System
Device Manager
CDROM
“SAMSUNG CD-R/RW SCW - ✽ ✽ ✽ ”
Check the Writing Software
You must check the CD-R/RW drive to operate rightly in the writing software.
Recorder
“SAMSUNG CD-R/RW SCW - ✽ ✽ ✽ ”
English
