12_ maintain tools and filter
Parquet brush (OPTIONAL)
• Vacuums dust in a wide area at once.
• Remove waste matter completely from the
inlet if the inlet is blocked.
Blanket brush (OPTIONAL)
1
Turbine
Brush
2 3
For picking up pet hair
and fibre on upholstery
and bed linen.
1. Remove waste matter completely when inlet is blocked.
2. Turn the lock button to ( ), and remove.
3. To reassemble, align the cover to the front of the main body and close. After closing the cover,
ensure that the lock button is turned to the ( ) position.
CAUTION
Use for bedclothes only. Be careful not to damage the brush during unclogging.
