Display Modes (HDMI/DVI Input)
Optimal resolution is 1360x768@60Hz.
Mode
Resolution
Horizontal Frequency (KHz)
Vertical Frequency (Hz)
Pixel Clock Frequency (MHz)
Sync Polarity (H / V)
IBM
640 x 350
31.469
70.086
25.175
+ / -
720 x 400
31.469
70.087
28.322
- / +
MAC
640 x 480
35.000
66.667
30.240
- / -
832 x 624
49.726
74.551
57.284
- / -
VESA DMT
640 x 480
31.469
59.940
25.175
- / -
37.861
72.809
31.500
- / -
37.500
75.000
31.500
- / -
800 x 600
37.879
60.317
40.000
+ / +
48.077
72.188
50.000
+ / +
46.875
75.000
49.500
+ / +
1024 x 768
48.363
60.004
65.000
- / -
56.476
70.069
75.000
- / -
60.023
75.029
78.750
+ / +
1360 x 768
47.712
60.015
85.500
+ / +
✎
✎
NOTE
x
For HDMI/DVI cable connection, you must use the
HDMI IN 1(DVI)
jack.
x
The interlace mode is not supported.
x
The set might operate abnormally if a non-standard video format is selected.
x
PC(D-Sub) input is not supported.
x
If an HDMI to DVI cable is connected to the
HDMI IN 1(DVI)
port, the audio does not work.
SERVICE
Connector for service only.
