Spectrum Analyzer Signal Standards
Index
Standard
Center
Span
Valid Channels
00h
AMPS / EIA 553 - Uplink
859000000
70000000
1-799, 990-1023
01h
AMPS / EIA 553 - Downlink
859000000
70000000
1-799, 990-1023
02h
C-450 (P) - Uplink
463500000
21000000
1-800
03h
C-450 (P) - Downlink
463500000
21000000
1-800
04h
C-450 (SA) - Uplink
462500000
15000000
1-247
05h
C-450 (SA) - Downlink
462500000
15000000
1-247
06h
CDMA US Cellular - Uplink
859000000
70000000
1-799, 990-1023
07h
CDMA US Cellular - Downlink
859000000
70000000
1-799, 990-1023
08h
CDMA US PCS - Uplink
1920000000
140000000
1-1199
09h
CDMA US PCS - Downlink
1920000000
140000000
1-1199
0Ah
CDMA Korea PCS - Uplink
1810000000
120000000
1-599
0Bh
CDMA Korea PCS - Downlink
1810000000
120000000
1-599
0Ch
CDMA Japan / ARIB - Uplink
878500000
93000000
1-799, 801-1039, 1041-1199
0Dh
CDMA Japan / ARIB - Downlink
878500000
93000000
1-799, 801-1039, 1041-1199
0Eh
CDMA China - 1 - Uplink
916000000
88000000
0-1000, 1329-2047
0Fh
CDMA China - 1 - Downlink
916000000
88000000
0-1000, 1329-2047
10h
CDMA China - 2 - Uplink
910000000
76000000
0-1000
11h
CDMA China - 2 - Downlink
910000000
76000000
0-1000
12h
CDMA2000 Class 0, Korea Cellular - Uplink
859000000
70000000
1-799, 990-1023
13h
CDMA2000 Class 0, Korea Cellular - Downlink
859000000
70000000
1-799, 990-1023
14h
CDMA2000 Class 0, N.A. Cellular - Uplink
859000000
70000000
1-799, 990-1023
15h
CDMA2000 Class 0, N.A. Cellular - Downlink
859000000
70000000
1-799, 990-1023
16h
CDMA2000 Class 1, N.A. PCS - Uplink
1920000000
140000000
0-1199
17h
CDMA2000 Class 1, N.A. PCS - Downlink
1920000000
140000000
0-1199
18h
CDMA2000 Class 2, (TACS Band) - Uplink
916000000
88000000
0-1100, 1329-2047
19h
CDMA2000 Class 2, (TACS Band) - Downlink
916000000
88000000
0-1100, 1329-2047
1Ah
CDMA2000 Class 3, (JTACS Band) - Uplink
878500000
93000000
1-799, 801-1039, 1041-1199
1Bh
CDMA2000 Class 3, (JTACS Band) - Downlink
878500000
93000000
1-799, 801-1039, 1041-1199
1Ch
CDMA2000 Class 4, Korea PCS - Uplink
1810000000
120000000
0-599
1Dh
CDMA2000 Class 4, Korea PCS - Downlink
1810000000
120000000
0-599
1Eh
CDMA2000 Class 5, (NMT-450-20 kHz) - Uplink
472500000
43000000
1039-1473, 1792-2016
1Fh
CDMA2000 Class 5, (NMT-450-20 kHz) - Downlink
472500000
43000000
1039-1473, 1792-2016
20h
CDMA2000 Class 5, (NMT-450-25 kHz) - Uplink
439500000
57000000
1-300, 539-871
21h
CDMA2000 Class 5, (NMT-450-25 kHz) - Downlink
439500000
57000000
1-300, 539-871
22h
CDMA2000 Class 6, IMT-2000 - Uplink
2045000000
250000000
0-1199
23h
CDMA2000 Class 6, IMT-2000 - Downlink
2045000000
250000000
0-1199
24h
CDMA2000 Class 7, N.A. 700 MHz Cellular - Uplink
770000000
48000000
0-359
25h
CDMA2000 Class 7, N.A. 700 MHz Cellular - Downlink
770000000
48000000
0-359
26h
Digital Mulitmedia Broadcasting (DMB)
2642500000
50000000
0
