Page 11
Control Byte
#
Name
Description
Watchdog
Timer
106 (6Ah)
Set Spectrum Analyzer
Resolution Bandwidth Freq
Sets the Spectrum Analyzer resolution BW frequency (obsolete)
Yes
107 (6Bh)
Set Spectrum Analyzer
Video Bandwidth Freq
Sets the Spectrum Analyzer video BW frequency (obsolete)
Yes
108 (6Ch)
Set Spectrum Analyzer
Sweep Mode
Sets the Spectrum Analyzer sweep mode
Yes
109 (6Dh)
Set Spectrum Analyzer
Marker to Peak
Sets specified marker to peak value of the sweep
Yes
110 (6Eh)
Set Spectrum Analyzer
Marker to Center
Sets the center frequency equal to the frequency of the specified marker
Yes
111 (6Fh)
Set Spectrum Analyzer
Attenuation
Sets the attenuation for the Site Master Spectrum Analyzer mode (obsolete)
Yes
112 (70h)
Set VNA Segmented Limit
Lines
Sets the position and On/Off status of the segmented limit lines for the VNA
modes
Yes
113 (71h)
Set Spectrum Analyzer
Multiple Limit
Sets the position and On/Off Status of a limit segment for the SPA mode
Yes
114 (72h)
Set Return Spectrum
Analyzer Sweep Time
If this is enabled, the duration of the current sweep (in milliseconds) will be
returned as 4 bytes via the serial port at the end of the sweep
Yes
115 (73h)
Set Reference Level Offset
Sets the value of the reference level offset
Yes
117 (0x75)
Read Marker Value
Returns the frequency location of the specified marker, and the value at that
location
Yes
118 (76h
Set Sweep Averaging
Sets the number of sweeps to average
Yes
120 (78h)
Field InstaCal
Initiates an InstaCal calibration
—-
124 (7Ch)
Read InstaCal Module
ASCII Serial Number
Returns the InstaCal Module serial number in ASCII
Yes
129 (81h)
Set Site Master Marker
(Peak/Valley)
Sets an individual marker in current measurement mode to either peak
(maximum) signal or valley (minimum) signal
Yes
133 (85h)
Set/Reset SPA External
Reference
Sets the external reference frequency for the spectrum analyzer
Yes
134 (86h)
Check External SPA
Reference
Returns the state of the SPA external reference
—-
136 (88h)
Set SPA Preamp State
Sets the state of the SPA preamp
Yes
140 (8Ch)
Set SPA Units
Sets the scale type (logarithmic or linear) and the units
Yes
141 (8Dh)
Set SPA Resolution
Bandwidth
Sets the resolution BW frequency for the Spectrum Analyzer
Yes
142 (8Eh)
Set SPA Video Bandwidth
Sets the video BW frequency for the Spectrum Analyzer
Yes
143 (8Fh)
Set SPA Attenuation
Sets the attenuation for the Spectrum Analyzer
Yes
145 (91h)
Set AM/FM Demod
Sets the AM/FM/SSB Demodulation state
Yes
197 (C5h)
Set Baud Rate
Sets the serial communication baud rate for this session
Yes
198 (C6h)
Set Language
Sets the Site Master display language
Yes
208 (D0h)
Query Time
Queries the Site Master for the current time in ASCII format
—-
221 (DDh)
Read Main Serial Number
Returns the Main (External) Serial Number as four bytes
Yes
255 (FFh)
Exit Remote Mode
Ends serial communications
—-
A001h
Set T1 Transmission Level
Sets the transmission level of T1 measurement mode
Yes
A002h
Set T1/E1 Clock Source
Sets the Clock Source of T1/E1 measurement mode
Yes
A003h
Set T1/E1 Pattern
Sets the data pattern of T1/E1 measurement mode
Yes
Site Master PM
5
