Rear Panel
ΠDVI INPUT
Connect to the digital video and audio
output jack of a device with DVI output.
´ MONITOR OUT (VIDEO / L-AUDIO-R)
Outputs for external devices
ˇ PC INPUT (RGB IN / AUDIO)
Connect to the video and audio output
jack on your PC.
¨ ONLY FOR SERVICE
Connector for service only.
ˆ S-VIDEO
Video and audio inputs for external
devices with an S-Video output, such as
a camcorder or VCR.
Ø AV (VIDEO / L-AUDIO-R)
Video and audio inputs for external
devices, such as a camcorder or VCR.
∏ COMPONENT
Video (Y/P b /P r ) and audio (L-AUDIO-R)
inputs for Component.
” ANT IN VHF/UHF (75Ω)
75Ω Coaxial connector for
Antenna/Cable Network.
’ EXT SPEAKER (8Ω)
Connectors for external speakers.
˝ POWER IN
Connect the supplied power cord.
