Color Tone
- Available in PC/DVI Mode Only
1) PC : Cool / Normal / Warm / Custom
2) DVI : Cool / Normal / Warm
Color Control
Adjust the individual R, G, B color controls.
- Available in PC Mode Only
1) Red
2) Green
3) Blue
Red
Green
Blue
If you adjust picture using Color Control function, Color Tone will turn to Custom
mode.
Image Lock
Image Lock is used to fine-tune and get the best image by
removing noise that creates unstable images with jitter and
shimmer. If satisfactory results are not obtained using the
Fine adjustment, use the Coarse adjustment and then use
Fine again.
- Available in Analog Mode Only
1) Coarse
: Adjust the screen so that all vertical lines (noise)
on the screen are removed. Then, use the
horizontal position adjustment menu to move the
screen to the center, as the screen position may
change after the noise has been removed.
2) Fine
: Removes noise such as horizontal stripes. If the
noise persists even after Fine tuning, repeat it after
adjusting the frequency (clock speed).
3) Sharpness
: Adjust the Sharpness.
4) H-Position
: Adjusts the screen location horizontally.
5) V-Position
: Adjusts the screen location vertically.
Coarse
Fine
Sharpness
H-Position
V-Position
Auto Adjustment
The values of Fine, Coarse, position are adjusted
automatically. If you change resolution in the control panel,
Auto function will be executed.
- Available in Analog Mode Only
Size
You can switch the Size.
- When the Aspect Ratio is 4:3, PIP is not available.
- When PIP is ON, the SIZE menu is not available.
1) Wide
2) 4:3
PIP Picture
When the PIP is on, you can adjust the PIP screen setting.
1) Contrast
: Adjusts the Contrast of the PIP window on the
screen.
2) Brightness
: Adjusts the Brightness of the PIP window on the
screen.
3) Sharpness
: Adjusts the Sharpness of the PIP window on the
screen
4) Color
: Adjusts the Color of the PIP window on the screen
5) Tint
: Adds a natural tone to the PIP window.
Contrast
Bightness
Sharpness
Color
Tint
