Samsung LS17MJAKSZ-XAX - Manual (Page 69)

General
General
Model Name SyncMaster 701N
LCD Panel
Size 17" Diagonal (43 cm)
Display area 337.92 mm (H) x 270.336 mm (V)
Pixel Pitch 0.264 mm (H) x 0.264 mm (V)
Type a-si TFT active matrix
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 56 ~ 75 Hz
Display Color
16.2 M Colors
Resolution
Optimum resolution 1280 x 1024@60 Hz
Maximum resolution 1280 x 1024@75 Hz
Input Signal, Terminated
RGB Analog
0,7 Vp-p Positive at 75 Ω
Separate H/V sync, Composite sync, SOG, TTL level positive or negative.
Maximum Pixel Clock
140 MHz
Power Supply
AC 100 ~ 240 VAC(+/- 10 %) , 60/50 Hz ± 3 Hz
Signal Cable
15pin-to-15pin D-sub cable, detachable
Power Consumption
SyncMaster 701N
