12
Introduction
User’s Manual
1. Power port : Connect the power cord for your
monitor to the power port on the back
of the monitor.
2.Signal cable :Connect the end of the signal cable
to your computer's video port
(video board,video card or graphics
card).
1. Signal cable : Connect the end of the signal cable to your computer's video port
(video board, video card or graphics card).
2. Power port : Connect the power cord for your monitor to the power port on the
back of the monitor.
3. Tilt/Swivel Base : You can separate the base from the monitor.
Note See Connecting Your Monitor for further information
regarding cable connections.
(The configuration at the back of the moniter
may vary from product to product.)
Rear
Bottom
