Pin Assignments
Figure 1: Male Type Figure 2: Male Type
Table 4. 15-Pin D-SUB connector
Sync.
Type
15-Pin Side of the Signal Cable
(Figure 1)
Cable Adapter
(Figure 2)
Pin No. Separate Composite Sync on Green Apple MacII
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Red
Green
Blue
GND
DDC Return
GND-R
GND-G
GND-B
Reserved
GND-Sync./
Self-Raster
GND
DDC Data
H-Sync.
V-Sync.
DDC Clock
Red
Green
Blue
GND
DDC Return
GND-R
GND-G
GND-B
Reserved
GND-Sync./
Self-Raster
GND
DDC Data
H-Sync.
Not Used
DDC Clock
Red
Green+Sync.
Blue
GND
DDC Return
GND-R
GND-G
GND-B
Reserved
GND-Sync./
Self-Raster
GND
DDC Data
Not Used
Not Used
DDC Clock
GND-R
Red
H/V Sync.
Sense 0
Green
GND-G
Sense 1
Reserved
Blue
Sense 2
GND
V-Sync.
GND-B
GND
H-Sync.
6 7 8 X 10
11 12 13 14 15
1 2 3 4 5
9 10 11 12 13 14 15
1 2 3 4 5 6 7 8
