English 20

Appendix

Specifications

Table 4. Specifications

LCD Monitor Panel

770TFT/170T

:

43 cm (17") LCD Monitor

0.264 mm Pixel pitch

870TFT

:

46 cm (18.1") LCD Monitor

0.2805 mm Pixel pitch

Viewing Angle: 80/80/80/80 (U/D/L/R) (Degrees)

* Synchronization

Horizontal:

30 kHz to 81 kHz

Vertical:

56 Hz to 85 Hz (~XGA)

60 Hz to 76 Hz (SXGA)

Display Colors

16.7 Million Colors

Maximum Resolution

Horizontal:

1280 Dots

Vertical: 1024

Lines

Active Display

770TFT/170T :

Horizontal: 338 ± 3 mm (13.3" ± 0.12”)

Vertical:

270 ± 3 mm (10.6" ± 0.12”)

870TFT :

Horizontal:

359.04 ± 3 mm (14.1" ± 0.12”)

Vertical:

287.23 ± 3 mm (11.3" ± 0.12”)

(Active display size is dependent upon signal timing and image
size selection.)

Input Signal, Terminated

Analog video 0.7 Vpp positive at 75

Separate sync, composite, and sync-on-green,
TMDS (SyncMaster 170T only)

Maximum Pixel Clock

135 MHz

Power Adapter

AC 90-264 Volt, 60 Hz/50 Hz ± 3 Hz

Power Consumption

42 W (Maximum), 40 W (Nominal)

Dimensions/Weight
(W x D x H)

770TFT/170T :

440 x 182 x 462 mm; 7.9 kg (17.32 x 7.16 x 18.19 in; 17.41 lbs)

870TFT :

461x 182x 465 mm; 8.3 kg (18.14 x 7.16 x 18.30 in; 18.29 lbs)

(All measurements approximate)

VESA Mounting Interface

100 mm x 100 mm
(For use with Specialty (Arm) Mounting hardware.)

Environmental Considerations

Operating Temperature: 50

°

F to 104

°

F (10

°

C to 40

°

C)

Humidity: 10% to 80%
Storage Temperature: -68

°

F to 113

°

F (-20

°

C to 45

°

C)

Humidity: 5% to 95%

NOTE:

Design and specifications are subject to change without prior notice.

* Referring to Preset timing modes, page 23.
