maintaining the tools and filters
_11
03
MAINT
AINING THE TOOLS AND FIL
TERS
•
Vacuums dust in a wide area at once.
•
Remove waste matter completely from
the inlet if the inlet is blocked.
PARQUET BRUSH (OPTIONAL)
BLANKET BRUSH (OPTIONAL)
1. Remove waste matter completely when inlet is blocked.
2. Turn the lock button to ( ), and remove.
3. To reassemble, align the cover to the front of the main body and close. After closing
the cover, ensure that the lock button is turned to the ( ) position.
Use for bedclothes only. Be careful not to damage the brush during unclogging.
CAUTION
1
Turbine
Brush
2
3
For picking up pet hair
and fibre on upholstery
and bed linen.
