o p e r a t I n G I n s t r U c t I o n s
AR-6G Rotisserie Operation & Care Manual • 16 AR-6G Rotisserie Operation & Care Manual • 16
to lIGht the bUrners:
1. Select corresponding gas valve knob. Rotate the knob
to the ignite position. (H=High)
2. If the burner fails to ignite after 5-seconds, turn valve
to the OFF position. Open the doors to allow the gas
to dissipate and repeat the ignition process.
3. After burner has ignited, rotate the gas valve to flame
height desired for cooking.
to shUt off bUrners:
Rotate the gas valve knob to the OFF position.
recommenDeD lIGhtInG seQUence
Natural Gas:  TOP  MIDDLE  BOTTOM
Propane Gas:  BOTTOM  MIDDLE  TOP
c o n t r o l s
The MAIN POWER switch is located on the left side
of the control panel.
The LIGHT SWITCH controls cook cavity and
Rotisserie logo light.
BURNER CONTROL AND CONTROL BURNER
FLAME HEIGHT is used to activate burner ignition
modules and adjust flame height.
Spit Rotation switches are labeled TOP, MIDDLE,
and BOTTOM. When in the ON position, each switch
will activate the corresponding double set of spits for
each switch.
EMERGENCY STOP is located in the center of
the control panel which shuts down the system
in an emergency.
COOK TIMER (2 hour maximum)
a
b
c
d
e
  



n a t u r a l
g a s
p r o p a n e
g a s
D o o r c a t c h
A magnetic door catch is used to keep door closed.
f
a b c d e f
