Fig. 1 View of the POE100 Series Media Converter
Fig. 2 Example connection between POE100, PD device and Fibre Cable
Fig. 3 POE100 Series to PD Device or POE Splitter (VOIP Phone)
RX
TX
TX
RX
VOIP PoE Phone,
(PoE PD) or PoE Splitter
POE100 Series
Media Converter
AC
100FX
Fibre Network
