4 - 3 0 4 - 3 0 4 - 3 0 4 - 3 0 4 - 3 0 C h a p t e r 4 : B I O S s e t u p C h a p t e r 4 : B I O S s e t u p C h a p t e r 4 : B I O S s e t u p C h a p t e r 4 : B I O S s e t u p C h a p t e r 4 : B I O S s e t u p
Silicon 3132 Controller [SATA2 Mode] Silicon 3132 Controller [SATA2 Mode] Silicon 3132 Controller [SATA2 Mode] Silicon 3132 Controller [SATA2 Mode] Silicon 3132 Controller [SATA2 Mode]
Allows you to set the onboard Silicon Image SATA RAID controller mode.
Configuration options: [SATA2 Mode] [RAID Mode] [Disabled]
ITE8211F Controller [Enabled] ITE8211F Controller [Enabled] ITE8211F Controller [Enabled] ITE8211F Controller [Enabled] ITE8211F Controller [Enabled]
Allows you to enable or disable the onboard ITE ® 8211F IDE controller.
Configuration options: [Disabled] [Enabled]
Detecting Device Time [Quick Mode]
Sets the time the ITE8211F IDE RAID controller detects devices
connected to the IDE RAID connectors.
Configuration options: [Standard Mode] [Quick Mode]
Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4] [2E8/IRQ3]
Parallel Port Address [378] Parallel Port Address [378] Parallel Port Address [378] Parallel Port Address [378] Parallel Port Address [378]
Allows you to select the Parallel Port base addresses.
Configuration options: [Disabled] [378] [278] [3BC]
Parallel Port Mode [ECP] Parallel Port Mode [ECP] Parallel Port Mode [ECP] Parallel Port Mode [ECP] Parallel Port Mode [ECP]
Allows you to select the Parallel Port mode.
Configuration options: [Normal] [Bi-directional] [EPP] [ECP]
E C P M o d e D M A C h a n n e l [ D M A 3 ] E C P M o d e D M A C h a n n e l [ D M A 3 ] E C P M o d e D M A C h a n n e l [ D M A 3 ] E C P M o d e D M A C h a n n e l [ D M A 3 ] E C P M o d e D M A C h a n n e l [ D M A 3 ]
Appears only when the Parallel Port Mode is set to [ECP]. This item
allows you to set the Parallel Port ECP DMA.
Configuration options: [DMA0] [DMA1] [DMA3]
Parallel Port IRQ [IRQ7]
Configuration options: [IRQ5] [IRQ7]
Onboard Game/MIDI Port [Disabled] Onboard Game/MIDI Port [Disabled] Onboard Game/MIDI Port [Disabled] Onboard Game/MIDI Port [Disabled] Onboard Game/MIDI Port [Disabled]
Allows you to select the Game Port address or to disable the port.
Configuration options: [Disabled] [200/300] [200/330] [208/300]
[208/330]
