www.avenview.com 8
1.6.2 I/O Connectors
Connectors Video Source
Input
Connectors
DVI IN
DVI
VGA
(DVI to VGA Adapter)
Component (YPbPr)
(DVI to VGA Adapter and VGA to Component Adapter)
1 x DVI
1 x VGA
(DVI to DVI/VGA Y Cable
1 x DVI
1 x Component
(DVI to DVI/VGA Y Cable and VGA to Component Adapter)
VGA VGA
Composite CVBS (NTSC/PAL0
Bridge Connectors 2 x DVI
Output
Connectors
Display
DVI-I OUT
DVI Display
VGA Display
(DVI to VGA Adapter)
1 x DVI Display
1 x VGA Display
(DVI to DVI/VGA Y Cable)
1.7 Before Installation

Put the product in an even and stable location. If the product falls down or drops, it may cause an
injury or malfunction.

Don’t place the product in too high temperature (over 50°C), too low temperature (under 0°C) or high
humidity.

Use the AC power adapter with correct specifications. If inappropriate power supply is used then it
may cause a fire.

Do not twist or pull by force ends of the optical cables. It can cause malfunction.

To prevent fire or shock hazards, do not expose this device to rain or moisture.

Do not immediately use after moving from low temperature to high temperature as this causes
condensation
