Section 3: Specifications and Supported Resolutions
3.1 Specifications
Model DVI-VIDEOWALL-4
Description 4 Display Dual Image Video Wall Processor
Output Displays 4
Dual Output Support Yes (DVI & VGA)
Video Loop Out Yes
Video Bandwidth
DVI Single Link - 4.95Gbps
VGA - 165 MHz
Component - 30 MHz
CVBS – 13.5 MHz
Supported Resolutions 480i / 480p / 720p / 1080i / 1080p (60) / 1920x1200@75 / 1600x1200@60
Audio Support No
Control RS232
Embedded Video Mixer Yes (Dual View)
Ability to Cascade Yes ( up to 255 units)
Input TMDS Signal 1.2 Volts (peak – peak)
ESD Protection Human body model - ± 15kV (air gap discharge) & ±8kV (contact discharge
Input
2 x VGA
1 x DVI
1 x Component
1 x Composite
1 x RS232
1 x RS485
Output
5 x DVI
4 x VGA
DVI Connector Type DVI-I (29-Pin female, digital only)
VGA Connector Type HD-15 (15-pin D-sub female)
RS232 Connector DE-9 (9-pin D-sub female)
RCA Connector 75Ω
RJ45 Connector WE/SS 8P8C with 2 LED indicators
Dimensions 23" x 17" x 3.5" (L x W x H)
Size 2U Rack-mount with ears
Power Supply AC 100-240V
Power Consumption 40 Watts (max)
Operating Temperature 0~40°C [32~104°F]
Storage Temperature -20~60°C [-4~140°F]
Relative Humidity 20~90% RH [no condensation]
