C. Contents

1. Main Unit
2. Remote control with one CR2025 Battery
3. Cigarette Lighter Adaptor Power Cable
4. Two (2) Brackets with four (4) Screws
5. Owner's Manual
6. RCA Cables ( Red, Yellow, and White)

D. Controls

Main Unit (Refer to Figure 1)

1. Power Button
2. Pause Button
3. Previous Button
4. Play Button
5. Next Button
6. Stop Button

7. Eject Button
8. Remote Control Sensor
9. S-Video Jack

10. Video Output Jack
11. Audio L Output Jack
12. Audio R Output Jack
13. Monitor Port 1
14. Monitor Port 2
15. DC 12V Jack
16. IR Input Jack

4

Figure1

9

10 11

12 16

13

14

15

1

2

3

4 5 6

8

7
