Connections
H
D
M
I I
N
2
HDMI IN 1
(DVI)
COMPONENT / AV IN
AUDIO VIDEO SERVICE
ANT IN
EXT (RGB)
DIGITAL
AUDIO OUT
(OPTICAL)
(5V 0.5A
)
OPTICAL EXT
AUDIO OUT
R-AUDIO-L P R P B Y
COMPONENT OUT AUDIO OUT
R-AUDIO-L
VIDEO OUT
R B
R B R G
W R
R
Y
Y W
W R
R W
RG
DVI OUT HDMI OUT AUDIO OUT
R-AUDIO-L
PC
R W
VHF/UHF Antenna
Cable
USB
or
TV Rear Panel
TV Side Panel
BD Player / PC
HDMI, HDMI/DVI connection
Audio connection
SCART connection
Headphone
connection
BD Player
Component connection
BD Player
AV connection
✎
The position of port may
differ depending on the
model.
✎
It supports both
Component and AV
connection in one
port.
VCR or DVD
✎
The PDP device may interfere with
an amateur radio or AM radio.
✎
When using two-way radio mobile
and portable units or amateur radio
or AM radio near by your TV, this
may cause the TV to malfunction.
