Asus P4BGV-MX - Manual (Page 9)

ix
CPU
Chipset
Front Side Bus (FSB)
Memory
Expansion slots
IDE
Audio
LAN
Special Features
Back Panel I/O Ports
Internal I/O
Connectors
P4BGV-MX specifications summary
(continued on the next page)
Socket 478 ofr Intel Pentium 4 Northwood/Willamette
processors with frequency up to 2.4+ GHz
Northbridge: Intel 845GV
Southbridge: Intel ICH4 (FW82801DB)
533/400 MHz
2 x DDR DIMM Sockets
Max. 2 GB unbuffered PC2100/1600 non-ECC DDR SDRAM
3 x PCI
2 x UltraDMA 100/66
RealTek 2-channel CODEC
RealTek 8101L PCI LAN integrated 10/100Mbps Fast
Ethernet
Power Loss Restart
ASUS JumperFree
BIOS write protections
CPU Throttle
1 x Parallel
1 x Serial
1 x VGA
1 x PS/2 Keyboard
1 x PS/2 Mouse
4 x USB 2.0
1 x RJ-45 Port
CPU/Chassis FAN connector
20 pin ATX power connector
4-pin AUX power connector
COM2 port
CD/AUX audio in (on audio model only)
Front panel audio connector (on audio model only)
