ASUS P4BGV-MX Motherboard 2-11
2.3.1 Primary and Secondary Master/Slave
Type [Auto]
Select [Auto] to automatically detect an IDE hard disk drive. If automatic
detection is successful, Setup automatically fills in the correct values for
the remaining fields on this sub-menu. If automatic detection fails, select
[User Type HDD] to manually enter the IDE hard disk drive parameters.
Refer to the next section for details.
[User Type HDD]
Manually enter the number of cylinders, heads and sectors per track for
the drive. Refer to the drive documentation or label for this information.
Before attempting to configure a hard disk drive, make sure you have the
correct configuration information supplied by the drive manufacturer.
Installed Memory [XXX MB]
This field automatically displays the amount of conventional memory
detected by the system during the boot process.
