SS100 Sensor Simulator
1. General
The SS100 is a device used when the Campbell Scientific CR1000/LoggerNet
Training Course is taught out-of-house. The SS100 is powered by a nominal
12VDC power source, typically the datalogger itself, and provides several
outputs typical of those from sensors commonly measured by Campbell
Scientific dataloggers.
The Training Course instructors may use the SS100 in a variety of simulations
of their own choosing or use the analogies in this manual.
2. Specifications
Supply Voltage
12VDC
Analog Outputs
0-2.2
VDC
Pulse Outputs
High Frequency Pulse: 0-5 VDC, 3-140 Hz, non-linear
Low Level AC: 1 VDC, 3-140 Hz, non-linear
Bridge Measurement
Full bridge circuit
Fixed resistors 5 Kohm
Variable resistor 10 Kohm
Switch Closure
Momentary push button switch, normally open
Approximate duration: 135 ms
3. Wind Speed and Direction Simulation
Sensor: Wind Speed and Direction
Wind Direction (Use SS100 Analog Output)
Range:
0-360°
Accuracy:
+/-
3%
Resolution:
1°
Wind Direction Voltage: 0-2200 mVDC
Wiring
SS100
CR1000
+ SE1
G
Multiplier and offset calculation:
Multiplier = 360 degrees / 2200 mV
Offset
=
0
